The LT1764EFE#TRPBF is a high-performance linear voltage regulator integrated circuit (IC) manufactured by Analog Devices, Inc. (ADI). As a PMIC (Power Management Integrated Circuit) device, it belongs to the category of Voltage Regulators - Linear, providing a single positive adjustable output voltage range from 1.21V to 20V with a maximum output current of 3A.
Key features of this product include:
- Adjustable output voltage from 1.21V to 20V, allowing flexible power supply configuration
- High output current capability of up to 3A, suitable for powering a variety of electronic devices
- Low voltage dropout of 0.45V at 3A, ensuring efficient power conversion
- Wide operating temperature range of -40°C to 125°C, making it suitable for diverse environmental conditions
- Integrated protection features such as over-current, over-temperature, and reverse polarity protection, enhancing reliability
- Small 16-TSSOP-EP (Thin Shrink Small Outline Package with Exposed Pad) package, enabling compact design integration
- RoHS compliance and lead-free construction, adhering to environmental regulations
The LT1764EFE#TRPBF is well-suited for a wide range of applications, including:
- Power supplies for industrial and consumer electronics
- Portable device power management
- Automotive electronics
- Telecommunications equipment
- Medical equipment
- General-purpose voltage regulation
Regarding compatibility and alternative models, the LT1764 series includes several variations with different package options and feature sets. Some equivalent or alternative models within the LT1764 family include:
- LT1764ESC#PBF (16-SOIC package)
- LT1764EFE#PBF (16-TSSOP package without exposed pad)
- LT1764EDD#PBF (16-QSOP package)
- LT1764EDD-1#PBF (16-QSOP package with different voltage range)
These alternative models may offer slight variations in package size, voltage range, or other specifications to cater to different design requirements and space constraints.
LT1764EFE#TRPBF (1)
LT1764EFE#TRPBF Key Technical Attributes
Manufacturer: ADI (Analog Devices, Inc.)
Manufacturer Part Number: LT1764EFE#TRPBF
Base Part Number: LT1764
LT1764EFE#TRPBF Packing Size
Type: 16-TSSOP-EP
Material: Tape & Reel (TR)
Size: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Pin Configuration: 16 pins
Thermal Characteristics: Operating Temperature -40°C ~ 125°C
Electrical Properties: Voltage - Output (Max) 20V, Current - Output 3A
LT1764EFE#TRPBF Application
This device is typically used in various applications including but not limited to telecommunications, networking, and sensitive RF supply circuits due to its ability to provide a stable and regulated output voltage over a varied range of input voltages and load conditions.
LT1764EFE#TRPBF Features
The LT1764EFE#TRPBF from ADI is a Linear Voltage Regulator IC providing an adjustable output from 1.21 V to 20 V and capable of delivering up to 3A of output current. It features low dropout voltage of 0.45V at maximum output, enhancing its efficiency in tighter spaces without the need for additional heat sinking. With a quiescent current of only 5mA, power consumption is minimized when in idle state. Additionally, the regulator ensures protection against overcurrent, overtemperature, and reverse polarity events, enhancing overall device reliability and longevity in harsh environments.
LT1764EFE#TRPBF Quality and Safety Features
The device adheres to RoHS compliance indicating lead-free components which are environment friendly. It is designed with a Moisture Sensitivity Level (MSL) of 1, implying unlimited floor life under normal environmental conditions. The embedded protection features guard against potential damage from overcurrent, overtemperature, and reverse polarity conditions.
LT1764EFE#TRPBF Compatibility
This regulator is compatible with a wide range of input voltages up to 20V and can regulate output voltages from 1.21V to 20V, allowing for flexible implementation across various electronic applications and circuit designs that require a reliable power source.
LT1764EFE#TRPBF Datasheet PDF
For complete, accurate, and detailed technical specifications for the LT1764EFE#TRPBF Linear Voltage Regulator, customers are encouraged to download the datasheet PDF available on our website. This authoritative resource is essential for engineers and buyers making informed decisions regarding their specific applications.
